System A – Two stage cutaway
- Frick screw compressor (250HP) ammonia injection cooled high stage
- Fuller compressor (100 HP) low stage
- RVS recirculating vessel
- RVS intercooler
- VIKING ammonia recirculating pumps
- COLMAC evaporative coil
- HANSEN valves
- Hot gas defrost system
System B - Single stage system using a turbo ice maker that is batch processing
- Frick screw compressor (60HP)/Thermo-siphon cooled
- RVS recirculating vessel
- Cornell ammonia recirculating pumps
- COLMAC evaporative coil
- HANSEN valves
- Evapco evaporative condenser with remote sump
- TURBO ice maker
- ALLEN BRADLEY MOTOR CONTROL CENTER (Stanion Wholesale Electric)
System C - Single stage system operating at 12 psig, continuous sub-cooled flake ice
- Vilter 442B (25 HP)
- HOWE two Scotsman ice flakers
- HASNSEN Valves
- EVAPCO Coil evaporative condenser
- Square D MOTOR CONTROL CENTER STATION
System E - Two stage system operating a "blast-cell." Unit operates at a -50 F ammonia temperature
- FRICK low-stage screw compressor (100 HP) thermo-siphon oil cooling
- FRICK high-stage screw compressor (100 HP) thermo-siphon oil cooling
- RVS inter-cooler vessel
- HANSEN valves, liquid level probes and level eyes
- RVS recirculating receiver package
- Buffalo ammonia recirculating pumps
- HENRY view ports
- EVAPCO evaporator
- EVAPCO evaporative condenser
- RVS high pressure receiver with internal thermo-siphon tank
- PALMER fiberglass remote sump for the evaporative condenser
- ROCKWELL AUTOMATION / ALLEN BRADLEY DIV. motor control center that includes frequency drives and supporting switch gear and control software
- STANION WHOLESALE ELECTRIC electrical supplies and materials to wire the system
- USPI oil filtering systems
